In The Winery         Around The Vineyard • March - April 2011


              Walls:  The walls on the crush pad should be          Crush Pad Access from Outside:  Makes sure
              durable and reasonably easy to clean.  Concrete,      to plan for forklift, pallet jack, truck, tractor trailer
              cinderblock, tile or other physically strong mate-    and drive on traffic by way of tractor and wagon.
              rials should be considered for at least the first 40   Most designs have at least two tractor trailer load-
              inches of height of the walls.  These are reasonably   ing dock stations so one may park a refer semi on
              cleaned and very durable to resist bumping from       the premise to chill fruit as needed.  Another dock
              pallet jacks, forklifts, tractors and other heavy     may be used to receive fruit or other items by
              items.  Above the 40 inches, if the masonry is not    way of tractor trailer.  If possible include a height
              extended, perhaps look at an easily cleaned attrac-   to load a box truck or pick up with some relative
              tive and durable surface such a metal or vinyl siding  ease and then make sure vineyard tractors and
              materials.                                            wagons may drive on the crush pad for delivery
                                                                    and perhaps pomace removal from the crush pad.
              Flooring Surface:  Mentioned earlier but worth        Many smart winery setups elevate their presses
              re-emphasizing.  Make sure the surface of the         high enough in the air so that pomace may be
              flooring will handle all predicted vehicles, such as   dumped directly into a wagon or manure spreader
              pallet jacks and forklifts, in terms of its thickness   to remove that pomace quickly and efficiently with
              and PSI ratings.  Also make sure the surface has      little shoveling. Think this through when deciding
              enough aggregate finish to avoid slipping of foot     on placement of the equipment.
              and vehicle traffic.
                                                                    Building Door Access Placement:  Make sure
              Mirrors:  An easy tool to implement, and rarely       to have at least one people door, with glass panes
              considered, if certain areas are difficult for forklift   , and one larger overhead door, with see though/
              and machinery operators to see.  Try and locate       drive through plastic strip doors added.  The over-
              a mirror placement that will allow sight to that      head door is usually where large tanks are brought
              area.  This could be in, near and around door ways.   in and out of the winery.  New glass shipments,
              Another area nice for mirrors is above any equip-     if arriving at this loading dock will need to have
              ment that has high hoppers filled by forklift.  This   access to the building and this door is often the
              will allow the operator to remain on the forklift,    door of choice due to its proximity to the loading
              yet, be able to see inside the hopper to know all     dock.
              the fruit has moved through the hopper before
              adding more or closing a press door for example.      Thresholds:  Make sure to design most of the
                                                                    crush pad, as well as the complete winery build-
              Catwalks:  Study your crush pad operation to          ing, with minimal raised thresholds in doorways or
              determine if you need catwalks to service, operate    between floors so as to allow for easy movements
              and clean certain machinery.  Can these catwalks      of items by way of pallet jack, forklift, dolly etc.
              have dual purpose by allowing winery production
              staff access the catwalk while also allowing tour     Vineyard Safety Assistance:  If your winery
              guides to accompany tour traffic through the same     has vineyard operations on the property or close
              area?  This can be a great marketing tool as well     by, review if one may place the potentially required
              as a great working tool.  Some wineries have suc-     outdoor chemical safety shower on the crush pad
              cessfully placed their hopper to the press along a    in case of emergency.  Check with someone who
              catwalk so winery workers may rinse and clean that  knows locality regulations to see if this is an option
              hopper carefully from that catwalk location. The      at reasonable savings.  In many cases this same
              same area can be used for customer tours.             shower may be enough for the winery lab and pro-
                                                                    duction needs.
              Crush Pad Access Into Building:  Many win-
              eries opt for a lay out that gives access to the      Non-Stationary Equipment:  If your winery
              tank room from the crush pad.  Often this is the      has movable equipment make sure to place elec-
              first place the juices or must will go so that layout   tric outlets appropriately to service these pieces
              makes logical sense.  Try and have easy access to     of equipment.  Plan to be able to crush reds and
              the lab, also, so winemakers can easily assess the    to press whites simultaneously if possible.  Many
              fruit and corrections, if desired, can be made quick-  pieces of equipment come with short flexible elec-
              ly and easily.                                        tric cords to them so take a proactive step, before
